By: Anushakti Nagar, Praveen Kumar, Raja Ramanna, Homi Bhabha
A versatile beamline for performing reflectivity, fluorescence, and absorption experiments in the soft x-ray region of 100–1500 eV is commissioned on a bending magnet port of the Indus-2 synchrotron source. A high vacuum 2-axis reflectometer with x, y, and z sample scanning stages is installed. This reflectometer is used to measure the reflectivity of large samples up to 300 mm in length and 5 kg in weight. This feature is useful for characterizing x-ray optical elements, such as mirrors, gratings, and multilayers. A flange mounted silicon drift detector is installed in the downstream of the reflectometer for soft x-ray fluorescence measurements. The soft x-ray absorption measurements are carried out in the total electron yield and partial fluorescence yield modes. Integration of three different experimental techniques in the experimental station makes the beamline versatile for materials science applications as it provides structural, chemical, and electronic state information by performing the required experiments in an identical environment. The beamline uses a varied line spacing plane grating monochromator and gives a high flux (∼10
